TC-1W; is a wrap around style tubing hanger that is designed to seal the annulus, but not suspend the tubing string itself. It seats inside the tubing head bowl and has a seal that is activated by engaging the lockdown pins. It can be used in conjunction with the BO-2 hanger coupling and B-2P, B-1 or KTH adapters.

Seal Material – Standard material for all tubing hangers is HNBR 80 to 90 durometer. – Viton, Aflas and high/low temp HNBR are available upon request.

Hanger Material – All tubing hangers are available in alloy, stainless or Inconel for all API trim specifications.
